EDS-510A Series User’s Manual Getting Started
2-4
6. The Console login screen will appear. Press Enter to open the Account pop-up selector and
then select either admin or user. Use the keyboard’s down arrow to move the cursor to the
Password field, enter the Console Password (this is the same as the Web Browser password;
leave the Password field blank if a console password has not been set), and then press Enter.
7. The EDS-510A’s Main Menu will be displayed. (NOTE: To modify the appearance of the
PComm Terminal Emulator window, select Font… under the Edit menu, and then choose the
desired formatting options.)
8. After entering the Main Menu, use the following keys to move the cursor, and to select
options.
Key Function
Up/Down/Left/Right arrows, or Tab Move the onscreen cursor
Enter Display & select options
Space Toggle options
Esc Previous Menu
To Next Page
