EDS-510A Series User’s Manual Featured Functions
3-67
Static Multicast Router Port
Setting Description Factory Default
Select/Deselect Select the option to select which ports will connect
to the multicast routers. It’s active only when IGMP
Snooping is enabled.
Disabled
NOTE
At least one switch must be designated the Querier or enable IGMP snooping and GMRP when
enabling Turbo Ring and IGMP snooping simultaneously.
IGMP Table
The EDS-510A displays the current active IGMP groups that were detected.
The information includes VID, Auto-learned Multicast Router Port, Static Multicast Router
Port, Querier Connected Port, and the IP and MAC addresses of active IGMP groups.
Add Static Multicast MAC
If required, the EDS-510A also supports adding multicast groups manually.
