EDS-510A Series User’s Manual Featured Functions
3-7
Network
The Network configuration allows users to configure both IPv4 and IPv6 parameters for
management access over the network. The EDS-510A series supports both IPv4 and IPv6, and can
be managed through either of these address types.
IPv4
The IPv4 settings include the switch’s IP address and subnet mask, as well as the IP address of the
default gateway. In addition, input cells are provided for the IP addresses of a 1st and 2nd DNS
server.
IPv6
IPv6 setting includes two distinct address types—Link-Local Unicast address and Global Unicast
address. A Link-Local address makes the switch accessible over IPv6 for all devices attached to
the same local subnet. To connect to a larger network with multiple segments, the switch must be
configured with a Global Unicast address.
See a brief explanation of each configuration item below.
Auto IP Configuration
Setting Description Factory Default
Disable Set up the EDS-510A’s IP address manually.
By DHCP The EDS-510A’s IP address will be assigned
automatically by the network’s DHCP server.
By BOOTP The EDS-510A’s IP address will be assigned
automatically by the network’s BOOTP server.
Disable
Switch IP Address
Setting Description Factory Default
IP Address of the
EDS-510A
Identifies the EDS-510A on a TCP/IP network. 192.168.127.253
