EDS-510A Series User’s Manual Featured Functions
3-6
Description
Setting Description Factory Default
Media type Displays the media type for each module’s port N/A
Name
Setting Description Factory Default
Max. 63 Characters Specify an alias for each port, and assist the
administrator in remembering important
information about the port.
E.g., PLC 1
None
Speed
Setting Description Factory Default
Auto Allows the port to use the IEEE 802.3u protocol
to negotiate with connected devices. The port and
connected devices will determine the best speed
for that connection.
100M-Full
100M-Half
10M-Full
10M-Half
Choose one of these fixed speed options if the
opposing Ethernet device has trouble
auto-negotiating line speed.
Auto
FDX Flow Ctrl
This setting enables or disables the flow control capability of this port when the “port
transmission speed” setting is in “auto” mode. The final result will be determined by the “auto”
process between the EDS-510A and connected devices.
Setting Description Factory Default
Enable Enables flow control for this port when in
auto-negotiate mode.
Disable Disables flow control for this port when in
auto-negotiate mode.
Disable
MDI/MDIX
Setting Description Factory Default
Auto Allows the port to auto detect the port type of the
opposing Ethernet device and change the port
type accordingly.
MDI
MDIX
Choose the MDI or MDIX option if the opposing
Ethernet device has trouble auto-negotiating port
type.
Auto
