EDS-510A Series User’s Manual Specifications
B-6
0x3683 1 word TR2 Ring 2 2nd Port status
0x0000:Port Disabled
0x0001:Not Redundant
0x0002:Link Down
0x0003:Blocked
0x0004:Learning
0x0005:Forwarding
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
0x3700 1 word Turbo Chain Switch Role
0x0000:Head
0x0001:Member
0x0002:Tail
0xFFFF: Turbo Chain Not Enable
0x3701 1 word Turbo Chain 1st Port status
0x0000: Link Down
0x0001: Blocking
0x0002: Blocked
0x0003: Forwarding
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
0x3702 1 word Turbo Chain 2nd Port status
0x0000: Link Down
0x0001: Blocking
0x0002: Blocked
0x0003: Forwarding
0xFFFF:Turbo Ring V2 Ring 2 Not Enable
