EDS-510A Series User’s Manual Getting Started
2-7
NOTE
Before accessing the EDS-510A’s web browser interface, first connect one of the switch’s RJ45
Ethernet ports to your Ethernet LAN, or connect directly to your PC’s Ethernet card (NIC). You
can establish a connection using either a straight-through or cross-over Ethernet cable.
NOTE
The EDS-510A’s default IP is 192.168.127.253.
Perform the following steps to access the EDS-510A’s web browser interface.
1. Open Internet Explorer and type EDS-510A’s IP address in the Address field. Press Enter to
establish the connection.
2. The web login page will open. Select the login account (Admin or User) and enter the
Password (this is the same as the Console password), and then click Login to continue. Leave
the Password field blank if a password has not been set.
NOTE
By default, the EDS-510A’s password is not set (i.e., is blank).
