Moxa Managed Ethernet Switch (UI_2.0_FW_5.x) User Manual
Enabling Multicast Filtering
Use the USB console or web interface to enable or disable IGMP Snooping and IGMP querying. If IGMP
Snooping is not enabled, then IP multicast traf f ic is always f orwarded, f looding the network.
IGMP Snooping
IGMP Snooping provides the ability to prune multicast traf fic so that it travels only to those end destinations
that require that traf f ic, thereby reducing the amount of traf f ic on the Ethernet LAN.
NOTE
IGMP Snooping will be disabled when Port-Based VLAN is enabled.
IGMP Snooping Setting
Enable IGMP Snooping (Global)
Enable/Disable
Select the Enable IGMP Snooping checkbox near the top of the
window to enable the IGMP Snooping f unction globally.
Disabled
Query Interval (sec)
by the user
Sets the query interval of the Querier f unction globally. Valid
settings are f rom 20 to 600 seconds.
125 seconds
Enable Multicast Fast Forwarding Mode
Enable/Disable
Select the Enable Multicast Fast Forwarding Mode checkbox to
achieve fast multicast forwarding path re-learning while the
ring redundant network is down.
Note: Turbo Ring V2 or Turbo Chain must be enabled.
Disabled
