Moxa Technologies ioLogik E1214-T User Manual

ioLogik E1200 Series Modbus/TCP Default Address Mappings
A-15
Parameter Name Description Start
Address
(decimal)
Point
Type
Start
Register
(decimal)
Length Access Type
DO_p2pSafeModeFla
g
0: OFF, 1: ON 4112 02:INPUT
STATUS
14113 4 R bit
DO_p2pStatus 0: OFF, 1: ON 4096 02:INPUT
STATUS
14097 4 R bit
DO_pulseCount 0036 03:HOLDI
NG
REGISTER
40037 4 R/W word
DO_pulseOffWidth unit: 1 ms 0068 03:HOLDI
NG
REGISTER
40069 4 R/W word
DO_pulseOnWidth unit: 1 ms 0052 03:HOLDI
NG
REGISTER
40053 4 R/W word
DO_pulseStatus 0: STOP, 1:
START
0016 01:COIL
STATUS
00017 4 R/W bit
DO_status 0: OFF, 1: ON 0000 01:COIL
STATUS
00001 4 R/W bit
DO-all_statusFromD
O-00
0: OFF, 1: ON 0032 03:HOLDI
NG
REGISTER
40033 1 R/W word
System
Parameter Name Description Start
Address
(decimal)
Point
Type
Start
Register
(decimal)
Length Access Type
deviceName Each byte
represents
ASCII code of
each character
5040 04:INPUT
REGISTER
35041 30 R word
deviceUpTime unit: sec(s) 5020 04:INPUT
REGISTER
35021 2 R word
firmwareVersion e.g. V1.2.3 ->
1st byte: 1,
2nd byte: 2,
3rd byte: 3
5029 04:INPUT
REGISTER
35030 2 R word
firmwareBuildDate e.g.
Build1605171
8 -->
16051718
5031 04:INPUT
REGISTER
35032 2 R word
lanIp e.g.
192.168.127.2
54 -> 1st
byte: 192, 2nd
byte: 168, 3rd
byte: 127, 4th
byte: 254
5027 04:INPUT
REGISTER
35028 2 R word
