Moxa Technologies ioLogik E1214-T User Manual

ioLogik E1200 Series EtherNet/IP Default Address Mappings
B-3
DO Channel Object (0x67)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT class revision
0x64 0x01 GET doIndex UINT DO - index
0x64 0x02 GET doMode BOOL DO - mode (0: DO, 1: Pulse)
0x64 0x03 SET doStatus BOOL DO - DO mode -
status (0: OFF, 1:
ON)
0x64 0x04 SET doPulseStatus BOOL DO - Pulse mode - status (0: STOP,
1: START)
0x64 0x05 SET doPulseCount UINT DO - Pulse mode - count
0x64 0x06 SET doPulseOnWidth UINT DO - Pulse mode -
ON width (unit:
1 ms)
0x64 0x07 SET doPulseOffWidth UINT DO - Pulse mode - OFF width (unit:
1 ms)
Relay Channel Object (0x6A)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT class revision
0x64 0x01 GET relayIndex UINT Relay - index
0x64 0x02 GET relayMode BOOL Relay - mode (0: Relay, 1: Pulse)
0x64 0x03 SET relayStatus BOOL Relay - Relay mode - status (0:
OFF, 1: ON)
0x64 0x04 SET relayPulseStatus BOOL Relay - Pulse mode - status (0:
STOP, 1: START)
0x64 0x05 SET relayPulseCount UINT Relay - Pulse mode - count
0x64 0x06 SET relayPulseOnWidth UINT Relay - Pulse mode - ON width
(unit: 1.5 s)
0x64 0x07 SET relayPulseOffWidth UINT Relay - Pulse mode - OFF width
(unit: 1.5 s)
0x64 0x08 GET relayTotalCount UDINT Relay - Relay mode - total count
0x64 0x09 GET relayCurrentCount UDINT Relay - Relay mode - current count
0x64 0x0A SET relayCurrentCount
Reset
BOOL Relay - Relay mode -
reset current
count (1: RESET)
AI Channel Object (0x6B)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT class revision
0x64
0x01
GET
aiIndex
UINT
AI - index
0x64 0x02 GET aiMode UINT AI - mode (0: 0-10 V, 1: 4-20
mA,
2: 0-20 mA, 4: 4-20 mA burnout)
0x64 0x03 GET aiValueRaw UINT AI - raw value
0x64 0x04 GET aiValueScaled REAL AI - scaled value
0x64 0x05 GET aiValueRawMin UINT AI - minimum raw value
0x64 0x06 GET aiValueRawMax UINT AI - maximum raw value
0x64 0x07 GET aiValueScaledMin REAL AI - minimum scaled value
0x64 0x08 GET aiValueScaledMax REAL AI - maximum scaled value
0x64 0x09 SET aiResetMinValue BOOL AI - reset minimum value (1:
RESET)
0x64 0x0A SET aiResetMaxValue BOOL AI - reset maximum value (1:
RESET)
0x64 0x0B GET aiStatus UINT AI -
status (0: normal, 1: burnout,
2: over range, 3. under range)
0x64 0x0C GET aiBurnoutValue REAL AI - burnout value
