Moxa Technologies ioLogik E1214-T User Manual

B
B. EtherNet/IP Default Address Mappings
ioLogik E1200 EtherNet/IP Map
Supported Service
Service Code Class Level Instance Level Service Name Description
0x05
No
Yes
Reset
Restart device
0x0E Yes Yes Get_Attribute_Single Read an attribute
0x10 No Yes Set_Attribute_Single Modify an attribute
Assembly Object (0x04)
Instance Attribute ID Access Name Data Type Description
0x00 0x01 GET Revision UINT Revision of this object
0x65 0x03 GET Input Data ARRAY of BYTE Data Map by Models
0x65 0x04 GET Size UINT Number of BYTE in attribute
0x03
0x66 0x03 SET Output Data ARRAY of BYTE Data Map by Models
0x66 0x04 GET Size UINT Number of BYTE in attribute
0x03
Input Data Map by Models
Model Channels BYTE # Acces
s
Name Data
Type
Description
ioLogik
E1210
DI-15…00
1…0
GET
diStatus
BOOL
DI - DI mode - status (0: OFF, 1: ON)
65…2 GET diCounterValue UDINT DI - Counter mode - value
ioLogik
E1211
DO-15…00 1…0 GET doStatus BOOL DO - DO mode - status (0: OFF, 1: ON)
ioLogik
E1212
DI-15…00 1…0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
65…2
GET
diCounterValue
UDINT
DI - Counter mode - value
DO-07…00 66 GET doStatus BOOL DO - DO mode - status (0: OFF, 1: ON)
ioLogik
E1213
DI-11…00 1…0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
49…2 GET diCounterValue UDINT DI - Counter mode - value
DO-07…00 50 GET doStatus BOOL DO - DO mode - status (0: OFF, 1: ON)
ioLogik
E1214
DI-05…00 0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
24…1 GET diCounterValue UDINT DI - Counter mode - value
RLY-05…0
0
25 GET relayStatus BOOL Relay - Relay mode - status (0: OFF, 1:
ON)
ioLogik
E1240
AI-07…00 15…0 GET aiValueRaw UINT AI - raw value
ioLogik
E1241
AO-03…00 7…0 GET aoValueRaw UINT AO - raw value
ioLogik
E1242
DI-07…00 0 GET diStatus BOOL DI - DI mode - status (0: OFF, 1: ON)
32…1 GET diCounterValue UDINT DI - Counter mode - value
DO-03…00
33
GET
doStatus
BOOL
DO - DO mode - status (0: OFF, 1: ON)
AI-03…00 41…34 GET aiValueRaw UINT AI - raw value
