NPort 5600 Series User’s Manual Web Console Configuration
5-27
Pair Connection Master Mode
When using Pair Connection Mode, you must select Pair Connection Master Mode for the
Operation mode of one of the NPort 5600 device servers. In effect, this NPort 5600 will be acting
as a TCP client.
TCP alive check time
Setting Factory Default Necessity
0 to 99 min
7 min
Required
0 min: TCP connection is not closed due to an idle TCP connection.
1 to 99 min: NPort 5600 closes the TCP connection automatically if there is no TCP activity for
the given time.
Destination IP address
Setting Factory Default Necessity
IP address or Domain Name
(E.g., 192.168.1.1)
blank Optional
TCP port No. 4001 Required
The Pair Connection “Master” will contact the network host that has this IP address. Data will be
transmitted through the port No. (4001 by default). Note that you must configure the same TCP
port No. for the device server acting as the Pair Connection “Slave.”
