NPort 5600 Series User’s Manual Web Console Configuration
5-28
Pair Connection Slave Mode
When using Pair Connection Mode, you must select Pair Connection Slave Mode for the
Operation mode of one of the NPort 5600 device servers. In effect, this NPort 5600 will be acting
as a TCP server.
TCP alive check time
Setting Factory Default Necessity
0 to 99 min
7 min
Required
0 min: TCP connection is not closed due to an idle TCP connection.
1 to 99 min: NPort 5600 closes the TCP connection automatically if there is no TCP activity for
the given time.
Local TCP port
Setting Factory Default Necessity
TCP port No. (e.g., 4001)
4001
Required
This Port No. must be the same port No. that you set up for the Pair Connection “Master” device
server.
