MR TAPCON 230 Expert User Manual

13 Technical data
Maschinenfabrik Reinhausen GmbH 2021158 7817454/02 ENTAPCON
®
230 Expert
13.11 Tap position capture / resistor contact series
Electrical isolation Test voltage power-frequency withstand volt-
age: 500V
eff
; 50Hz; 1min
Tap position capture 35tap positions, 2,000ohms
13.12 Ambient conditions
Operating temperature -25...+70°C
Storage temperature -30...+85°C (with battery)
Relative humidity 5...95%, non-condensing
Contamination level 2
Protection class I
Degree of protection Front: IP54
Rear: IP20
With optional control cabinet: IP66
Maximum installation alti-
tude
3,000m above mean sea level
Minimum clearance to
other devices / control
cabinet
Above/below: 88.9mm (3.5in; equivalent to 2RU), be-
hind 30mm (1.2in)
Table82: Permissible ambient conditions
13.13 Standards and directives
Electromagnetic compatibility IEC61000-6-2, IEC61000-6-4,
IEC61000-6-5
EN60255-26
KN61000-6-2, KN61000-6-4
FCC47 CFR Part 15 B
ICES-003
Electrical safety IEC61010-1
IEC61010-2-201
IEC61010-2-030
EN61010-1
UL61010-1
CAN/CSA-C22.2 No. 61010-1
Measurement relays and protective de-
vices
IEC60255-1:2009 Section 6.10.1, 6.10.2
and 6.10.4
IEC60255-27:2013 Section 10.6.4.2,
10.6.4.3, 10.6.4.4 and 10.6.5.3
