13 Technical data
Maschinenfabrik Reinhausen GmbH 2021 1477817454/02 EN TAPCON
®
230 Expert
13 Technical data
13.1 Display elements
Display 5″ TFT colour display
LEDs 3 LEDs for operation display and messages
▪ POWER, AVR STATUS, ALARM
▪ RAISE, LOWER, AUTO, MANUAL, REMOTE
13.2 Materials
Front Aluminum, plastic
Tray/rear Stainless steel
13.3 Dimensions
W x H x D 218mm x 324mm x 130mm (8.58in x 12.76in x
5.12in) (without mating connector)
Mating connector 20mm (0.79in)
13.4 Power supply
Permissible voltage range 85 to 265VAC/VDC
U
N
: 100...240V AC
U
N
: 100...240V DC
Max. nominal power consumption 25W
Permissible frequency range 50/60Hz
Overvoltage category OC III
Surge test voltage 5kV, 1.2µs/50µs (IEC60255-27)
Internal fuse 250V AC, 1.25A, 5 x 20mm, T charac-
teristic (slow acting), breaking capacity H
(min. 1,500A), operating temperature
-30°C…+100°C)
Table55: Power supply
Interface Pin Description
2 L
1 N
Table56: Connection X9
