MR TAPCON 230 Expert User Manual

9 Operation
Maschinenfabrik Reinhausen GmbH 202188 7817454/02 ENTAPCON
®
230 Expert
Events
Log
No.
Event Time
16
Limit value P>>
15
Limit value P>
18
Limit value Q<<
17 Limit value Q<
12
Ambient conditions ...
18.03.2020
04:35:17/576
17.03.2020
10:56:59/669
16.03.2020
08:22:11/125
12.03.2020
01:33:22/845
10.02.2020
14:21:49/602
#
32
31
30
29
28
Export
Filter
1 / 100+
Home
Events
Information
Recorder
Settings
EN CHANGE REBOOT admin 06.04.2020 13:08
Figure44: Event memory
Filtering events
1. Press the Filter button.
2. Enter the desired time period.
3. Select the checkbox and enter the desired event number.
ð The event text is displayed.
4. Select the desired event categories and the desired event status.
5. Press the Search button to display the desired events.
Exporting events
You can export the event memory entries currently displayed as a csv file. If
you first create a filter, only the filtered entries are exported.
To export the events, proceed as follows:
ü First connect using Connect PC or connect a storage medium to the USB
port on the CPUI module.
1. Press the Export button.
2. Select the desired option for data transmission (PC or USB).
ð The data is exported.
9.1.11 User administration
User administration is based on a system of roles. You must assign a role to
every user. You can define access rights to parameters and events for each
role.
