6 Mounting
Maschinenfabrik Reinhausen GmbH 2021 417817454/02 EN TAPCON
®
230 Expert
Excessive line capacitance can prevent the relay contacts from interrupting
the contact current. In control circuits operated with alternating current, take
into account the effect of the line capacitance of long control cables on the
function of the relay contacts.
If you want to route Ethernet connections from a control cabinet or building,
we recommend using fiber-optic cables (in accordance with the
IEC61850-90-4 recommendation).
Cable Interface Cable type Conductor cross-sec-
tion
Max. length
Power supply (external) X9 Unshielded 1.5mm²
Voltage measurement UI-X7 Shielded
Current measurement UI-X7 Unshielded 2.5 mm²
Digital signal inputs DI16 Shielded 4mm² 400 m (<25 Ω/km)
Digital signal outputs DO8 Shielded 1.5mm²
Analog signal inputs AI4 Shielded 1 mm² 400 m (<25 Ω/km)
RS232, D-SUB 9-pole COM X3 Shielded 0.25mm² 25 m
RS485 COM-X6 Shielded 0.25mm² 140m
CAN bus COM-X6 Shielded 0.75mm² 2000m (total CAN bus)
Ethernet RJ45 X2, X3 Min. CAT5, shielded
S/FTP
100m
Ethernet FO COM X4 Duplex LC multi-
mode, Om3, 1310nm
2000m
110VDC output X8 Unshielded 1.5mm²
RJ45 patch cables Min. CAT5, shielded
S/FTP
approx. 30cm
Table10: Recommendation for connection cables
*) Observe line capacitance, see note above.
6.4.2 Electromagnetic compatibility
The device has been developed in accordance with applicable EMC stan-
dards. The following points must be noted in order to maintain the EMC
standards.
6.4.2.1 Wiring requirement of installation site
Note the following when selecting the installation site:
The system's overvoltage protection must be effective.
The system's ground connection must comply with all technical regula-
tions.
