MR TAPCON 230 Expert - Digital Inputs

13 Technical data
Maschinenfabrik Reinhausen GmbH 2021 1517817454/02 EN TAPCON
®
230 Expert
Interface X5 Pin Description
8 DTR (O)
7 DCD (I)
6 GND
5 RXD (I)
4 TXD (O)
3 VCC/OUT
5V/12V
2 RTS (O)
1 CTS (I)
Table63: Serial interface RS232 CPU:X5
13.7 Digital inputs
DI16
Inputs (plug-based electrical
isolation)
2 x 8
Nominal voltage 110VDC
Max. operating voltage 143VDC
Logical0 ≤ 55VDC
Logical 1 ≥ 82.5VDC
Input current 0.9mA
Simultaneity factor
(at 65°C ambient tempera-
ture)
Max. 13 inputs
Table64: DI 16-110V technical data
Interface Pin Description
1
2
3
4
5
6
7
8
9
10
10 Common reference (common)
9 Common reference (common)
8 Input 7
7 Input 6
6 Input 5
5 Input 4
4 Input 3
3 Input 2
2 Input 1
1 Input 0
Table65: ConnectorX1 (group 0)
