9 Operation
Maschinenfabrik Reinhausen GmbH 2021 837817454/02 EN TAPCON
®
230 Expert
9.1.7.3 Linking status messages
You can link each event with a status message. The device provides 10
generic status messages for this purpose. When you link a message to an
event, the device sets the data point to "On" when the event occurs. When
the event stops, the device sets the data point to "Off". A parameter is avail-
able for each available SCADA message.
To forward control system commands, you need to link the control system
messages to the General purpose input or Generic SCADA command
events.
ü The desired event number is known [►Section 9.1.10, Page 87].
1. Go to Settings > Parameters > System > Link messages.
2. Select the desired parameter.
3. Enter the desired event number.
4. Press the Accept button to save the modified parameter.
Generic status message X
You can use this parameter to link the SCADA message with an event mes-
sage. To do so, enter the desired event number.
If you enter event number 500, the link is disabled.
9.1.8 Configuring analog inputs
You can flexibly configure the device's analog inputs and assign device
functions.
The device supports analog sensors with linear characteristic curves and
only outputs analog signals with linear characteristic curves.
