Timeout for response confirmation
You can use this parameter to set the timeout for response confirmation for
unsolicited messages.
Unsolicited messages
You can use this parameter to set whether the device is to support unso-
licited messages. If you activate unsolicited messages, the device sends a
message via the control system every time a value is changed.
Destination address
You can use this parameter to set the destination master link address.
Timeout
You can use this parameter to set the timeout for unsolicited messages.
Repetition of unsolicited messages
You can use this parameter to set how often the device is to send an unso-
licited message until it receives a response from the DNP3 master.
9.1.7 Linking signals and events
The device enables you to link 12 digital inputs (GPI) and control system
commands (SCADA) with device functions, digital outputs (GPO) and control
system messages.
The digital inputs available are each permanently linked to a General pur-
pose input event message and the control system commands available are
each permanently linked to a Generic SCADA command event message for
this purpose.
Input/command Event message
Digital input 1 General purpose input 1
Digital input 2 General purpose input 2
... ...
Generic SCADA command 1 Generic SCADA command 1
Generic SCADA command 2 Generic SCADA command 2
... ...
Table20: Linking of digital inputs and control system commands with event messages
You can link the event messages with device functions, digital outputs and
control system messages. You can also link all other event messages (e.g.
Undervoltage U<) with digital outputs and control system messages. Corre-
sponding parameters, for which you need to enter the relevant event num-
ber, are provided for this purpose.
