MSA Description
AirGo 15
2.3.4.1. Option – Q – with Quick-Fill Coupling
Fig. 5 Pressure reducer SingleLine
1 Single line
2 Cylinder connection
3 Quick-Fill coupling
The Quick-Fill coupling is a high-pressure safety coupling which is fitted directly
on the pressure reducer ( Fig. 2).
It is then possible to fill 300 bar compressed air cylinder(s) whilst the compressed
air breathing apparatus is still donned. The connector of the pressure reducer is
arranged so that a 200 bar compressed air cylinder cannot be connected in order
to avoid inadvertent overfilling.
On compressed air breathing apparatus with Quick-Fill couplings, the
use of 200 bar compressed air cylinders is not possible.
For further information please observe the separate Operation Manual
for the Quick-Fill System (Part No. D4075049).
