MSA AirGo - Changing the Straps and Belt; Changing the Shoulder Straps

GB
MSA Maintenance and Care
AirGo 47
4.4. Changing the Straps and Belt
The shoulder straps and the hip belt are fastened to the back plate with metal
buckles ( Fig. 33 and Fig. 34).
For removing the straps and the belt you must pull up the buckles slightly, tilt
them and push them out of the slots in the back plate.
4.4.1. Changing the Shoulder Straps
Fig. 33 AirGo pro harness Fig. 34 AirGo compact harness
1 Line retainer 4 Shoulder strap buckles
2 Shoulder strap buckles 5 Hip belt back stop
3 Hip belt mounting slot
(1) Loosen the line retainer and remove the pressure line from the shoulder
strap.
(2) Remove the shoulder straps from the slots on the top of the back plate.
(3) Remove the shoulder straps from the slots on the bottom of the back plate.
(4) Assemble in reverse order.
4
3
5
2
1
