MSA AirGo - Cleaning and Disinfection of Automaxx on Fix Pneumatics

GB
Maintenance and Care MSA
44 AirGo
4.3.5. Cleaning and disinfection of AutoMaXX on Fix pneumatics
Existing Fix medium pressure line (without coupling) must be exchanged with
standard medium pressure line ( Section 9.4) for pressurised cleaning/
disinfection and/or testing on test unit.
(1) Pull off AutoMaXX protective cap as follows:
For AutoMaXX-AS
 With one hand push and hold down both operating buttons, with the
other hand push together both snap-on hooks and push off the
protective cap.
For AutoMaXX-AE
 Turn handwheel until the safety clamp below the black operating button
is visible through the handwheel opening.
Fig. 29 Housing
1 Securing clamp (only AutoMaXX-AE and AutoMaXX-N)
 Push in safety clamp with a screwdriver, simultaneously push both
operating buttons and pull off handwheel.
 With one hand push and hold down both operating buttons, with the
other hand push together both snap-on hooks and push off the protective
cap.
For AutoMaXX-N
 Turn handwheel until the safety clamp below an operating button is
visible through the handwheel opening.
 Push in safety clamp with a screwdriver, simultaneously push both
operating buttons and pull off handwheel.
 With one hand push and hold down both operating buttons, with the
other hand push together both snap-on hooks and push off the
protective cap.
1
