MSA Description
AirGo 7
2. Description
Fig. 1 Compressed air breathing apparatus AirGo (here model AirGo pro)
1 Manifold 8 Handle
2 Cylinder separator 9 Stop bracket (U-clip)
3 Cylinder retaining strap 10 Hip belt plate (Option)
4 Cylinder support 11 Quick-Fill coupling (Option)
5 Cylinder buckle 12 Pressure reducer
6 Shoulder strap 13 Pneumatic system (here SingleLine)
7 Back plate 14 Hip belt
The back plate consists of an anatomically designed plate of antistatic plastic with
handles for easy transport of the apparatus. The pressure reducing valve is
located in the lower section of the back plate. On the upper part of the back plate,
a cylinder support is attached with integrated line guide.
The carrying belts and the hip belt are adjustable in length.
One or two compressed air cylinders can be placed in the cylinder support. The
cylinder strap is freely adjustable and after inserting the compressed air
cylinder(s), it is tightened and secured using the cylinder buckle.
The structure of the compressed air breathing apparatus is based on a modular
design. This allows the user to configure the compressed air breathing apparatus
from the modules available to match his specific requirements.
5
