GB
Compressed Air Cylinders with alphaCLICK 2 MSA
56
AirGo
5. Compressed Air Cylinders with alphaCLICK 2
5.1. Changing of Compressed Air Cylinders to alphaCLICK 2
All usual compressed air cylinders with standard valve threads [EN 144-2] can be
easily equipped with the alphaCLICK 2 coupling system.
This means they can be used efficiently when combined with compressed air
breathing apparatus and uses the advantages of the innovative coupling system.
The alphaCLICK 2 cylinder adaptor is not equipped with a flow restrictor.
Fig. 44 Changing to alphaCLICK 2
1 alphaCLICK 2 cylinder adaptor
2 Cylinder valve
Attention!
When changing the compressed air cylinder(s) do not hold on to the
handwheel of the cylinder valve.
This could unintentionally open the cylinder valve through which
compressed air at high pressure could escape from the cylinder, out of
control.
(1) Check that the cylinder valve is closed.
(2) Thread the alphaCLICK 2 cylinder adaptor with a specific torque of
20-30 Nm into the cylinder valve.
1
