Compressed Air Cylinders with alphaCLICK 2 MSA
58 AirGo
Attention!
When being pressurised, cylinder must not be swivelled, as this can
cause damage to the alphaCLICK 2 filling coupling.
This is particularly important if a water basin for cooling is used while
filling.
(4) Fill the compressed air cylinder using the operating lever.
(5) Once the compressed air cylinder has been filled, close the cylinder valve.
(6) Depressurise the connection between the filling panel and the cylinder.
(7) Turn the handwheel of the alphaCLICK 2 filling coupling on the filling panel
clockwise first and upon reaching the stop, press in the direction of the filling
panel.
 The cylinder adaptor releases from the alphaCLICK 2 filling coupling.
(8) Remove compressed air cylinder from the alphaCLICK 2 filling coupling.
(9) Secure the alphaCLICK 2 filling coupling with blind plug.
