30
Operation
FL500 UV/IR Flame Detector
US
4.3.2 Alarm Test Feature
To use the Alarm Test feature, do the following:
(1) Connect one contact of a normally open, momentary switch to TB1 Terminal 4.
(2) Connect the other contact to TB1 Terminals 9 and 10 (COM).
(3) Activate the switch for the period set for the time delay (2 - 10 seconds).
• If the device senses the source, it immediately sends Alarm Low output, then the time-delayed
Alarm High ouput. After 1 to 8 seconds, the device resets the non-latching Alarm Low and Alarm
High conditions. Latching Alarm Low and Alarm High conditions stay latched until they are reset
manually. Refer to Section 3.5.4 "Alarm Reset Switch" for instructions.
• If the device does not sense the source, it sends Fault output and does the test again every
10 seconds.
The Alarm Test feature can be used through Modbus and HART.
Multiple devices cannot be put in a daisy-chain configuration to do testing for Alarm High
output.
