Appendix I: IMPACT NS50 Specifications
General
Dimensions
410mm x 327mm x 69mm
Weight
5.9kg packaged
Connectivity
4 x MST composite fibre ports (1000Base-LX)
4 x PoE ports
2 x 802.11b/g Radio ports
4 x RP-TNC antenna ports (with diversity support)
Enclosure Ingress
Protection (IP) rating
Powder-coated stainless steel enclosure, sealed to comply with an Ingress
Protection standard rating of IP65
Operating Temperature
0ºC to 50ºC (operating)
-20ºC to 80ºC (storage)
Operating Humidity
5- 95%
Power
Supply Voltage
8-54 VDC operating (PoE requires a 15-54 VDC supply. <15V will cause under
voltage lockout of the PoE 48V rail,
>54V may damage connected PoE devices)
60 VDC maximum input voltage (>60V will damage the unit)
External Power Supply
Recommendations
AC to DC power supply with galvanically isolated output(s)
48VDC output(s) (nominal)
With 6A breaker/fusing in line with each 48V output
Protection
Replaceable slow blow thermal fuses (on voltage arrestor/transient
suppression board.)
The voltage arrestor has a 3A anti-surge/slow-blow fuse (F106) and two 2A
anti-surge/slow-blow fuses (F107 & F108)
Power
Consumption
Idle (W)
Maximum
(W)
Part
Number
Configuration
PoE 48V
rail
Disabled
PoE 48V rail
Enabled
PoE 48V
rail
Disabled
PoE 48V rail
Enabled
NS5001
1 x Access Point Radio, 2 x
Gbps Fibre Ports
7.8
8.6
10.5
11.3
NS5002
2 x Access Point Radio, 2 x
Gbps Fibre Ports
9.9
10.4
12.2
13.0
