NS50 wireless network switch

User Manual

Revision C

© 2012 MST Global

Commercial in Confidence

ii

Revision History

Revision

Change

Date

A

User Manual for NS50 hardware and

firmware February 2012

2.22.16

February 2012

B

Updated for firmware 2.24.2

February 2012

C

Updated power supply recommendations

Textual content-legal

Layout 19.05.17

May 2017

Table of Contents

Revision History2
Copyright and Disclaimer3
- Copyright3
- Warning3
- Disclaimer3
Contact Information4
About this Manual5
- Conventions Used in the Manual5
- Icons5
- Related Publications6
- Additional Support6
- Table of Contents7
Chapter 1: Understanding the NS50 Wireless Network Switch11
- Hardware Overview12
- System Layout14
- Connectivity15
Chapter 2: Network System Design18
- Installation Types and Coverage19
- Power Requirements19
- Choosing Antennas19
- Placement of NS50 Units20
- Placement of Antennas20
- Determining Distance between Wireless Network Switches22
Chapter 3: Installation24
- NS50 Mounting Options25
- Antenna Mounting Options25
- Installation Schemes26
- Connecting Power to the NS5033
- Handling Composite Cable During Installation33
- Connecting Composite Cable to the NS5033
- Standard Composite and Fibre Cable Lengths36
- Connecting Ethernet Cable to the NS5036
- Connecting F-LINK Terminated Composite Cable to the NS5038
- Connecting Antennas to the NS5041
- Manual Reset and Reboot43
Chapter 4: Understanding Vlans45
- Understanding Trunk and Access Ports46
- Vlans and Wireless Networks48
- Native VLAN49
Chapter 5: Configuration Using the Web Interface50
- Logging Onto the Web Browser Interface51
- Configuration Screen52
- Status Tab53
- Tools Tab61
- Setting Tab69
Chapter 6: Centralised Configuration Management92
- Device Management Overview93
- TFTP Server Overview99
  - Editing Site Configuration Files100
  - Editing Device Configuration Files101
- TFTP Parameters102
Appendix A: Troubleshooting Guide113
Appendix B: Composite Cable Testing115
- 2012 MST Global Commercial in Confidence115
  - B1: Visual Inspection of the Fibre Optic Cable115
  - B2: Measuring and Testing for Power Loss115
Appendix C: Ethernet Cable Specifications117
Appendix D: Device Discovery118
Appendix E: Time Zone Indices and Offsets120
Appendix F: Connecting a PC to an IMPACT Network Device124
Appendix G: Maintenance Check List126
Appendix H: Acronyms128
Appendix I: IMPACT NS50 Specifications129
Appendix J: Hardware Warranty132
