MST Impact NS5004 User Manual

NS50 wireless network switch
User Manual
Revision C
Chapter 3: Installation
© 2012 MST Global
Commercial in Confidence
21
3.3.4 Installation at an Intersection
An example installation scheme for an intersection is shown in Figure 12: Installation Scheme at an
intersection.
 A panel antenna is clamped to a mounting pole, and is chemically adhered into the mine roof.
 The panel antenna is angled to provide wide wireless coverage at an intersection.
 A Yagi antenna is installed in the roof providing directional coverage down a straight drive. Each
antenna is connected to a WAC in the NS50.
 The network switch is cable tied to the rock mesh, connected to the composite cable that provides
power and network connectivity.
 The network switch also acts as a link for power and network connectivity to devices in the next
location.
