NS50 wireless network switch
User Manual
Revision C
Chapter 3: Installation
© 2012 MST Global
Commercial in Confidence
24
IMPORTANT: Protect all connectors and sockets from dust and grit, with minimal
exposure during installation. Any unused sockets must be covered by the supplied
dust caps at all times during installation. Any unused sockets must be covered by
the supplied dust caps at all times.
Step
Procedure
Illustration
1
Loosen the thumbscrew on the retention
arm.
2
Slide out the retention arm from the NS50.
3
Push down on the locking catch for the port
and remove the cover.
