NS50 wireless network switch
User Manual
Revision C
Chapter 5: Configuration Using the Web Interface
© 2012 MST Global
Commercial in Confidence
62
Figure 29: LAN configuration screen
To edit LAN settings, click in the selected field in the dialog box. LAN settings are described in the table
below.
Field
Description
Recommended Settings
Get LAN IP from
DHCP (Dynamic) or Static IP (Manual)
Default is DHCP. If Static IP is
selected, the following fields must be filled
in.
IP Address
The IP address of the WAC.
A different IP address is required for each
WAC in a network.
Subnet Mask
Identifies the subnet the IP address
belongs to for the WAC.
The default subnet mask is 255.255.255.0.
Gateway
The IP address of the default gateway
to be used by the WAC.
Settings are dependent on the site's
network design.
Primary DNS
The DNS server used by the WAC
when looking up host names.
Settings are dependent on the site's DNS
design.
Secondary DNS
The backup DNS server used by the
WAC when looking up host names.
Settings are dependent on the site's DNS
design.
Local Domain Name
Local domain name for the network.
Leave the field blank if you do not wish to
add a domain name.
If the device is left on DHCP, only the following fields are shown. These values will function as above,
only if they are not defined by the DHCP server.
