Connect to a home theatre receiver – Audio only
• To determine your best connection, refer to Audio Connection Options
• This video connection method does not support HD video. For more information, see Connect an HDTV – Audio
Only
Set-top box
Optical
S/PDIF
RCA-type
Audio
These connections serve the
same purpose, use only one
Video in
Sample HDTV Audio Inputs
