8.11.2 Air filter – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 4–20 Nm
F30044239 1
Air filter – Removal and installa-
tion
1. Release clamp (2).
2. Remove air filter (1) and clamp (2) from con-
necting flange of intake housing (3).
3. Verify that there are no objects in the con-
necting flange of the intake housing (3) and
clean it.
4. Place new air filter (1) with clamp (2) onto in-
take housing (3).
5. Tighten screw on clamp (2) with torque wrench to the specified tightening torque.
Name Size Type Lubricant Value/Standard
Screw - Tightening torque 5 Nm
MW15409/04E 2015-08 | Task Description | 111
TIM-ID: 0000005457 - 010
