4.3 Main engine dimensions
Main engine dimensions
Engine model Overall length (A) Overall width (B)
Overall height (C)
12V 2000 M91 approx. 2470 mm approx. 1400 mm approx. 1460 mm
16V 2000 M91 approx. 2815 mm approx. 1400 mm approx. 1520 mm
34 | Technical Data | MW15409/04E 2015-08
TIM-ID: 0000002156 - 001
