MTU 16V2000M91 - Operation; LOP controls (without Blue Line automation system)

5 Operation
5.1 LOP controls (without Blue Line automation system)
LOP – Controls
Item Color Inscription
Meaning / Function
1 White F1 Function keys to control the man-machine interface.
Functions vary and are displayed on the LCD screen.
2 White F2
3 White F3
4 White F4
5 White F5
6 White ALARM ACKNOWL Pressing the button the first time stops alarm signaliza-
tion.
Pressing the button a second time acknowledges an ac-
tive alarm.
LED (spot) lights up when an alarm is active.
7 White DIM ↑ Holding down the button increases LCD background illu-
mination.
8 White DIM ↓ Holding down the button decreases LCD background illu-
mination.
