8.19 Belt Drive
8.19.1 Drive belt – Condition check
Preconditions
☑ Engine is stopped and starting disabled.
☑ Guard is removed.
Drive belt – Condition check
Item Findings Action
Drive belt A Singular cracks None
Drive belt B Cracks on entire circumference Replace (→ Page 140)
Drive belt C Chunking
Drive belt Belt is oily, shows signs of over-
heating
MW15409/04E 2015-08 | Task Description | 137
TIM-ID: 0000000920 - 011
