8.22 Universal Shaft
8.22.1 Universal shaft – Greasing
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Lithium-soap greases according to DIN2–KP K–20
NOTICE
Damage to component.
Severe material damage!
• Do not press in grease at high pressure or with hard strokes.
• Permissible lubrication pressure max. 15 bar.
Universal shaft – Greasing
1. Remove guard from universal shaft.
2. Clean the two grease nipples on each joint
half.
3. Press grease into all nipples until it emerges
at the star seals and sealing rings.
4. Reinstall guard.
142 | Task Description | MW15409/04E 2015-08
TIM-ID: 0000007659 - 003
