8.5.2 Injection pump – Removal and installation
Preconditions
☑ Engine is stopped and starting disabled.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Torque wrench, 20-100 Nm
F30026582 1
Ratchet adapter
F30027340 1
Box wrench
F30038493 1
Spider patch spanner
F30027424 1
Spider patch spanner
F30027425 1
Torque wrench, 0.5-5 Nm
0015384230 1
Assembly compound (Kluthe Hakuform 30-15)
X00067260
Sealing ring
(→ Spare Parts Catalog)
Sealing ring
(→ Spare Parts Catalog)
DANGER
Rotating and moving engine parts.
Risk of crushing, danger of parts of the body being caught or pulled in!
• Before cranking the engine with starter system, make sure that there are no persons in the engine's
danger zone.
WARNING
Fuels are combustible and explosive.
Risk of fire and explosion!
• Avoid open flames, electrical sparks and ignition sources.
• Do not smoke.
• Wear protective clothing, protective gloves, and safety glasses / facial protection.
Preparatory steps
1. Close fuel supply line upstream of fuel filter.
2. Remove engine control system (→ Page 149).
3. Drain fuel (→ Page 87).
4. Remove charge-air pipes and all seals.
78 | Task Description | MW15409/04E 2015-08
TIM-ID: 0000004579 - 008
