MTU 16V2000M91 - Oil Filtration; Cooling

8.16 Oil Filtration / Cooling
8.16.1 Oil dipstick — Marking
Preconditions
☑ Engine is stopped and starting disabled.
☑ MTU Fluids and Lubricants Specifications (A001061/..) are available.
Special tools, Material, Spare parts
Designation / Use Part No. Qty.
Engine oil
Oil dipstick
(→ Spare Parts Catalog)
WARNING
Hot oil.
Oil can contain combustion residues which are harmful to health.
Risk of injury and poisoning!
• Wear protective clothing, gloves, and goggles / safety mask.
• Avoid contact with skin.
• Do not inhale oil vapor.
Note: In the case of new engines and spare parts, oil dipsticks are delivered without marks.
Oil dipstick — Marking
1. Extract or drain off all oil from oil pan.
2. Pull out oil dipstick.
3. Fill in minimum oil quantity (→ engine data).
4. Insert oil dipstick and pull out again.
5. Mark a "Min." notch on the oil dipstick. Max. notch depth 1 mm.
6. Shorten oil dipstick as necessary.
7. Fill in maximum oil quantity (→ engine data).
8. Insert oil dipstick and pull out again.
9. Mark a "Max." notch on the oil dipstick. Max. notch depth 1 mm.
118 | Task Description | MW15409/04E 2015-08
TIM-ID: 0000006267 - 004
