Item Color Inscription
Meaning / Function
9 White LAMP TEST Pressing the button initiates lamp test.
10 Red TEST OVERSPEED Pressing the button initiates overspeed test.
LED (spot) lights up as long as the overspeed test is run-
ning.
11 Green (depending on type of
gearbox and propul-
sion)
FPP: Pressing the button engages gear ahead.
CPP, WJ, VS: Pressing the button engages clutch.
LED (spot) lights up when GCU feedback is active.
12 Green FPP, CPP, WJ, VS: Pressing the button disengages clutch.
LED (spot) lights up when GCU feedback is active.
13 Green FPP: Pressing the button engages gear astern.
CPP, VS: No function assigned.
WJ: Holding down the button provides flushing of water jet
intake channel (water-jet reverse) .
LED (spot) lights up when GCU feedback is active.
14 White ENGINE SPEED IN-
CREASE
Engine speed is increased as long as the button is held
down.
15 White ENGINE SPEED DE-
CREASE
Engine speed is decreased as long as the button is held
down.
16 Green READY FOR OPERA-
TION
Pressing the button causes changeover between “Not
ready for operation” and “Ready for operation” status.
LED (spot) lights up at "Ready for operation" position.
17 Green LOCAL OPERATION Pressing the button activates changeover between local
and remote control mode.
LED (spot) lights up when local mode is active.
18 White START Pressing the button initiates the automatic engine start
sequence.
LED (spot) lights up as long as the starting procedure is
running.
19 White STOP Pressing the button initiates automatic engine stopping
procedure.
LED (spot) lights up as long as the STOP signal is available
(also if transmitted from RCS).
20 Red EMERGENCY STOP Pressing the button initiates an immediate emergency en-
gine stop.
LED (spot) flashes once the emergency stop has been
tripped and until the alarm has been acknowledged.
36 | Operation | MW15409/04E 2015-08
