RAW WATER CIRCUIT (open circuit)
Number of cylinders 12
16
Raw water pump inlet pressure, min. L bar -0.4 -0.3
Raw water pump inlet pressure, max. L bar +0.5 +0.5
Pressure loss in external raw water system, max. L bar 0.7 0.7
LUBE OIL SYSTEM
Number of cylinders 12
16
Lube oil temperature before engine, from R °C 83 91
Lube oil temperature before engine, to R °C 88 97
Lube oil operating pressure before engine, from R bar 7.5 6.1
Lube oil operating pressure before engine, to R bar 8.5 7.1
Lube oil operating pressure, low idle (meas. point: before engine) R bar 3.5 3.0
FUEL SYSTEM
Number of cylinders 12
16
Fuel pressure at supply connection on engine, min. (when engine
is starting)
L bar -0.3 -0.3
Fuel pressure at supply connection on engine, min. (when engine
is running)
L bar -0.3 -0.3
Fuel pressure at supply connection on engine, max. (when engine
is starting)
L bar +0.5 +0.5
Fuel supply flow, max. R liter/min 5.1 6.9
STARTING (electric)
Number of cylinders 12
16
Rated starter voltage (standard design) R V= 24 24
STARTING (pneumatic starter)
Number of cylinders 12
16
Starting-air pressure before starter motor, min. R bar 21* 24*
Starting-air pressure before starter motor, max. R bar 30 30
INCLINATIONS, STANDARD OIL SYSTEM (Reference: waterline)
Number of cylinders 12
16
Longitudinal inclination, continuous max., driving end down (Op-
tion: max. operating inclinations)
L degrees 15 15
Longitudinal inclination, temporary max., driving end down (Op-
tion: max. operating inclinations)
L degrees 22.5 22.5
Longitudinal inclination, continuous max., driving end up (Option:
max. operating inclinations)
L degrees 5 0
Longitudinal inclination, temporary max., driving end up (Option:
max. operating inclinations)
L degrees 10 6
MW15409/04E 2015-08 | Technical Data | 31
TIM-ID: 0000002886 - 001
