5
Basic control principles
Layout of work screen
Opens the “Results” screen.
Opens the “Parameters” screen.
Opens the “Tank Filling” screen.
Opens the “Folding” screen.
Switches between manual and automatic regulation of the application rate.
Opens a screen with additional functions.
Activates or deactivates operation of the spraying areas.
Opens the “ME-Joystick” screen.
Switches between two levels of icons.
Shows the next page with function icons.
Spray data area
The following information is shown in this area:
Selected icons in the spray data area
Depending on the configuration, the following icons may appear:
The application rate will be automatically regulated.
The current value (current application rate) appears next to it.
No flow. The main valve cannot be opened because one of the
requirements has not been fulfilled:
- Speed slower than “Sprayer off below” [
➙
