Operating job computer on the field
Documenting work results
6
The sliding axle is being retracted.
Sloping the implement
You can slope the orchard or vineyard sprayer hydraulically during operation.
This is how you reach the screen with this function:
Use the following function keys to operate the function:
Slopes the implement to the left.
Slopes the implement to the right.
The following icons may appear on the screen:
The implement is being sloped to the left.
The implement is being sloped to the right.
Documenting work results
You can document your work in the “Counters” screen.
On the “Counters” screen, there are two types of counter:
▪ Trip counter – documents the work until it is deleted.
▪ Total counter – documents the work since initial start-up.
The “Counters” screen has the following information:
▪ Quantity - Applied quantity.
▪ Area - Applied area.
▪ Distance – Distance driven during the application.
▪ Work time – Total duration of the application.
Use the following function keys to operate the function:
Resets the “Volume” counter.
Resets the “Area” counter.
