9
Technical specifications
Technical specifications of the job computer
Technical specifications
Technical specifications of the job computer
ECU-MIDI 3.0 job computer
32-bit ARM Cortex™-M4 CPU 168 MHz, 2048 KB flash; 256 KB RAM
32-bit ARM Cortex™-M4 CPU 168 MHz, 2048 KB flash; 256 KB RAM
SPI-Flash 16 MB; SDRAM 16 MB; FRAM 16kByte
Connections:
▪ 42-pin connector for connecting actuators/sensors
▪ 2x 16-pin connector for power supply and CAN (ISOBUS & Salve
BUS)
The connectors can be locked and equipped with single conductor
Up to 3 CAN and 1 LIN, Ethernet via additional card (optional)
Power supply: 12 V electrical system (9-16 V), max. load 30 A (50 A fuse in the cabel
Power input (IN): 500 mA (at 14.4 V without power output, without supply to external
Housing: Anodized aluminium continuous cast casing, plastic lid with EPDM
seal and pressure compensation element, stainless steel screws
Environmental tests: Vibration and shock testing in accordance with DIN EN 60068-2
Temperature testing in accordance with IEC68-2-14-Nb, IEC68-2-30
and IEC68-2-14Na
Protection testing in accordance with DIN EN 60529
Approx. 262 mm x 148 mm x 62 mm (L x W x H, without connector)
Available languages
You can set the following languages in the software for the operation of the implement:
Bulgarian, Croatian, Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Portuguese, Polish, Romanian, Russian, Serbian,
Slovak, Slovenian, Spanish, Swedish, Turkish
