Configuring the job computer
Calibrating the flow meter
2. Weigh the tank.
3. Switch to the “CALIBRATION” screen:
> > >
⇨ The following screen appears:
4.
- Select the tank method.
⇨ The following screen appears:
5.
- Start application
⇨ During application, the number of impulses will be counted on the “CALIBRATION – Main
flow meter” screen.
6. Apply a few hundred litres. Do not fully empty the tank. This prevents air bubbles from forming
and distorting the results.
7.
- Stop the application.
⇨ The application will be stopped.
⇨ No impulses are counted on the display.
8.
- Stop calibration.
9. Weigh the tank.
10. Enter the applied quantity in litres on the “Enter water volume” line.
11.
- Exit the screen.
