GENERATOR SERVICE AND TROUBLESHOOTING MANUAL — REV. #0 (08/29/23) — PAGE 81
ECU
-
845 AC FAULT CODES
Table 11. ECU-845 AC Defaults (Isuzu/Volvo)
Setpoint Defaults
I4JHA : DCA70 I4JHB : DCA125 IZ4F : DCA400 V4F : DCA600
Menu Structure I4JHA0-9-0-45 I4JHB0-9-0-45 IZ4F0-7-0-45 V4F0-12-0-9
|-> HI WYE RATED VOLTS LL 480 480 480 480
|-> HI WYE RATED VOLTS LN 277 277 277 277
|-> HI WYE RATED PHASE AMPS 84 150 481 722
|-> HI WYE RATED PHASE KVA 23 42 133 200
|-> HI WYE RATED PHASE KW 19 33 107 160
|-> HI WYE RATED PHASE KVAR 14 25 80 120
|-> RATINGS 50HZ N/A N/A N/A N/A
