5.4.3. staVideo (subsection 3)
In the following table only OBJECTNUMBER part of the identifier (OID) is listed.
VIDEO SIGNAL
OBJECTNUMBER
Name
Access
Type
Description
1
videoSignal
Locked
read-only
Integer
Video signal status:
0 – not locked
1 – locked
2
videoSignal
Width
read-only
Integer
Video signal width in pixels
3
videoSignal
Height
read-only
Integer
Video signal height in pixels
4
videoSignal
HorizFreq
read-only
Integer
Horizontal frequency of video
signal in Hz
5
videoSignal
VertFreq
read-only
Integer
Vertical frequency of video
signal in Hz
6
videoSignal
Clock
read-only
integer
Video clock frequency in Hz
7
videoSignal
Modeline
read-only
integer
Video modeline
8
8
videoSignal
Type
read-only
string
Video input type:
VGA – analog VGA
DVI SL – digital single-link
DVI DL – digital dual-link
DP – DisplayPort
9
videoSignalAnalog
ResolutionModeTable
read-only
table
Table containing analog
resolution modelines
8
Modeline – configuration line in xorg.conf (or file of similar function) that provides information to the display
server about a connected display device that contains information on how to use it at a given resolution.
