5.4.4. staRtsp (subsection 5)
In the following table only OBJECTNUMBER part of the identifier (OID) is listed.
OBJECTNUMBER
Name
Access
Type
Description
1
rtspCodec
read-only
String
Codec used:
H264 or LOSSLESS
2
rtspFramesOut
read-only
Counter
Number of video frames on
RTSP output
3
rtpsIFramesOut
read-only
Counter
Number of I-frames on RTSP
output
4
rtspSessionTable
-
Table
Table listing active RTSP sessions
Example:
The OID for rtspCodec is 1.3.6.1.4.1.46236.1.2.5.1.0 as the OID is constructed in the
following way:
VIDEO GRABBER
.
SECTION
.
SUBSECTION
.
OBJECTNUMBER
.
1.3.6.1.4.1.46236.1
.
2
.
5
.
1
.
0
The entries in the rtspSessionTable have the following format:
OBJECTNUMBER
Name
Access
Type
Description
1
rtspSession
AddressType
read-only
Enum
Type of IP address of the RTSP
client:
0 – unknown
1 – ipv4
2 – ipv6
3 – ip4z
4 – ip6z
16 – dns
2
rtspSession
Address
read-only
String
IP address of the RTSP client
3
rtspSession
Port
read-only
Integer
TCP/UDP port of RTSP client
4
rtspSession
Type
read-only
String
Protocol used:
TCP or UDP
5
rtspSession
BytesOUT
read-only
Counter
Number of bytes sent
6
rtspSession
PacketsOut
read-only
Counter
Number of packets sent
7
rtspSession
Uptime
read-only
Integer
Number of seconds since
session start
