-19-
8.2. Correction
Menu Function Value Function Description
Ordinal Number in the "Parameters" Hot Menu
Speed corr. -99,0...+999,9
Cons.corr. -99,0...+999,9
Ref.mileage 10...99,9
Ref.expence 5...99,9
-20...20
V Batt.corr. -0,5...+0,5 The entered correction is added to the measured battery voltage.
Init.milge
Init.time,h Initial Engine Hours 0…99999
Polarity Nozzle Polarity
Tachometer
Lin.tank сallib. Launches the linear fuel tank callibration (by 2 or by 7 points), see page 12
Calibr.7 reset Resets the calibration table created during the 7-point calibration process.
Tank tare Fuel Tank Callibration Launches nonlinear fuel tank callibration, see page 12
Trim cal.min. -2...-10
Trim cal.max. -1...90
Incline сalibr.
№
Speed Correction
(%)
Independently calculated correction for speed and distance traveled.
To find percentage of the correction value the following formular is used:
correction=((Ref*(100+у%))/from) - 100, where
"Ref" - Mileage reference value;
"F rom- Measured mileage value in the display "Average/Reset;
"у%" - Speed correction value entered before measurements.
The correction takes effect from the moment the coefficient is set.
Fuel Consumption
Correction
(%)
Independently calculated correction for fuel efficency.
To find percentage of the correction value the following formular is used:
correction=((Ref*(100+у%))/from) - 100, where
"Ref." - Fuel consumption reference value;
"From" - Measured fuel consumption value in the display "Average/Cumulative";
"у%" - Consumption correction value entered before measurements.
Reference Mileage
(km)
Actual mileage value of the water vehicle for automatically calculated correction factor for
speed and distance travelled. Uses data received from the GPS navigator (if a built-in GPS
module of the device is not used). The procedure for automatic calculation: see 4.2. page 11
Reference Fuel
Consumption
(litres)
Actual amount of fuel consumed to calculate automatically the correction factor for fuel
consumption. Value from a filling station or a filling tank should be used.
The procedure for automatic calculation: see clause 4.3. page 11
Air/Water/Engine
corr.
Air/Water/Engine
Temperature
Correction (°С)
Correction of the displayed ambient air/ overboard water/ engine temperature (depending on the
type of sensor used and settings in "Sources - Signature temp.").
Battery Voltage
Correction (V)
Initial Mileage
(km)
Created to enter the actual mileage before the trip computer was installed. The entered
numbers will be added to the "Total Mileage" parameter of the "Average/Reset" display and it
will display the actual mileage of the vehicle, not only from the moment the trip computer was
installed.
Created to set the real number of the engine operating hours before the trip computer was
installed.
> -
+
For correct calculation of fuel consumption, select the polarity of the control signal on the
injection plug. If installed properly, the fuel consumption increases with increasing gas.
Only for "Display of installations - Sources - Speed Force (or Flow Force)"
Tachometer
Correction
>1
2
4
To correctly indicate the engine revolutions depending on the injection system (sequential,
paired or parallel injection), set the coefficient at which the idle speed is correctly displayed.
Only for "Display of Installations - Sources - Speed Force (or Flow Force)".
Linear Tank
Callibration
Reset 7 points Tank
Calllibration
Calibration of the
Lowerest Position of
the Trim Sensor (deg)
Sets the point of the maximum submerged position of the boat engine.
To calibrate, turn on the ignition or start the engine, lower the engine as much as possible and
enter the value of the angle of its position in degrees (the current value of the trim sensor
voltage will be displayed on the screen).
Only when connected to the trim sensor.
Calibration of the
Highest Position of
the Trim Sensor (deg)
Sets the point of the maximum position of the boat engine raised from the water.
To calibrate, turn on the ignition or start the engine, raise the engine as much as possible and
enter the value of the angle of its position in degrees (the current value of the trim sensor
voltage will be displayed on the screen).
Only when connected to the trim sensor.
Accelerometer
Calibration
Accelerometer calibration (indicates the level position of the vessel for further correct
calculation of roll and pitch). Before calibration, place the water vehicle on a flat surface
(without waves) and confirm the zero position setting with the "SET" button.
