1). Compatible engines and displayed parameters
-3-
Multitronics CL-950E shows different sets of parameters depending on the engine type and selected communication
protocol. However there are common parameters which it displays regardless of the engine type or protocol and identical
for all protocols which are listed in the table below.
HONDA
BF 115A (2005-2006)
BF 115D (all years)
BF 130A (2005-2006)
BF 135A (2004-2006)
BF 135A4 (all years)
BF 150A (2004-2006)
BF 175A (2003-2007)
BF 250A (all years)
BF 40D (all years)
BF 50D (all years)
BF 75A (all years)
BF 90D (all years)
BFP 60A (all years)
SUZUKI
DF15A/20A (s/n:310001...)
DF40/50 (1999...)
DF40A/50A (s/n:110001...)
DF60A (2010...)
DF60/70 (1998...)
DF70A/80A/90A (2009...)
DF90/115 (2001...)
DF100 (2009...)
DF140 (2002...)
DF150/175 (2006...)
DF200/225/250 (2004...)
DF250S (2008...)
DF300 (2007...)
YAMAHA
HPDI:
Z150, LZ150, VZ150
Z175, LZ175, VZ175
Z200, LZ200, VZ200
Z225, LZ225, VZ225
Z250, LZ250, VZ250
Z300, LZ300, VZ300
EFI 4-stroke:
F30, F40
F50, FT50, T50
F60, FT60, T60
F70, F75, F80, F90, F100
F115, FL115, LF115
F150, FL150, LF150
F200, FL200, LF200
F225, FL225, LF225
F250, FL250, LF250
F300, FL300, LF300
F350, FL350, LF350
NMEA2000
water vehicles compatible with NMEA2000.
Common parameters regardless of the selected protocol
1 Trim, degree 7 Average consumption per 100 km per trip 13 speed
2 Roll, degree 8 Trip cost 14 rpm
3 Trip time 9 Date/Time 15 consumption l/100km; l/h
4 Fuel consumed per trip 10 Remaining fuel 16 temperature (external sensor, option)
5 Mileage per trip 11 Mileage prognosis 17 trim
6 Average speed per trip 12 Battery voltage
Yamaha basic parameters 13 Oxygen sensor voltage * 5 Knocking control count
1 Engine rpm 14 Fuel pressure * 6 Fuel pressure minimum
2 Intake manifold pressure * 15 Idle control position * 7 System failures
3
Throttle position
*If the parameter is missing you will see "---", 8 Engine ID
4 Throttle position 2 * depends on the engine Yamaha engine hours
5 On-board voltage Yamaha additional parameters 1 0-1000 rpm
6 Injection time 1 Atmosphere pressure 2 1000-2000 rpm
7 Ignition advance angle 2 Total engine hours 3 2000-3000 rpm
8 Engine temperature, degree * Yamaha service records 4 3000-4000 rpm
9 Intake air temperature 1 Maximum engine speed 5 4000-5000 rpm
10 Water temperature* (coolant analogue) 2 Over rev. count 6 5000-6000 rpm
11 Engine oil pressure * 3 Overheat count 7 6000-7000 rpm
12 Speed 4 Low oil pressure count
+ Faults reading and reset
Suzuki basic parameters 7 6000-7000 rpm 16 NO.OF SP SENSOR FAILURE
1 Engine rpm 8 Total (hours) 17 NO.OF TP SENSOR FAILURE
2 Intake manifold pressure 9 Total (minutes) 18 NO.OF NEUTRAL SW FAILURE
3 Throttle position sensor* Suzuki service records 19 NO.OF CHECK CODE WIRE FAILURE
4 On-board voltage 1 NO.OF MAP SENSOR FAILURE 20 NO.OF CMP FAILURE(VVT_STDB)
5 Injection time 2 NO.OF CKP SENSOR FAILURE 21 NO.OF CMP FAILURE(VVT_PORT)
6 Injection advance angle 3 NO.OF IAC VALVE FAILURE 22 NO.OF VVT ADVANCE FAILURE(S)
7 Cylinder temperature 4 NO.OF CMP SENSOR FAILURE 23 NO.OF VVT ADVANCE FAILURE(P)
8 Intake air temperature 5 NO.OF INTAKE FAILURE 24 NO.OF OCV FAILURE(VVT_STDB)
9 Idle control position 6 NO.OF SYL. TEMP. SENSOR FAILURE 25 NO.OF O2 SENSOR FAILURE
* If the parameter is missing you will see 7 NO.OF IAT SENSOR FAILURE 26 NO.OF TRIM SENSOR FAILURE
8 NO.OF EX. TEMP. SENSOR FAILURE(S) 27 NO.OF KNOCK SENSOR FAILURE
Suzuki engine hours 9 NO.OF OVER-REVOLUTION 28 NO.OF OIL PRESSURE SW FAILURE
1 0-1000 rpm 10 NO.OF LOW OIL PRESSURE 29 NO.OF OCV FAILURE(VVT_PORT)
2 1000-2000 rpm 11 NO.OF OVERHEAT(GRADIENT) 30 NO.OF WATER IN FUEL
3 2000-3000 rpm 12 NO.OF OVERHEAT(TEMP.) 31 NO.OF O2 SENSOR HEATER FAILURE
4 3000-4000 rpm 13 NO.OF LOW BATTERY VOLTAGE 32 System failures
5 4000-5000 rpm 14 NO.OF FUEL INJECTOR FAILURE 33 Engine ID
6 5000-6000 rpm 15 NO.OF EX. TEMP. SENSOR FAILURE(P)
+ Faults reading (without reset)
"---", depends on the engine
Honda basic parameters 3 Atmosphere pressure sensor 19 Charge indicator
1 Engine rpm 4 Injection error sygnal 20 Pump control
2 Engine oil temperature 5 21 Inlet air bypass valve
3 Intake air temperature 6 Lambda probe heating 22 Number of VTEC triggers
4 Intake pressure sensor 7 23 Engine hours
5 Throttle position sensor 8 Lambda probe heating current 24 Engine hours on 100% throttle
6 On-board voltage 9 Idle speed valve, neutral 25 Engine hours on trawl
7 Injection time 10 Idle speed valve, trawl 26 Engine hours at idle
8 Injection advance angle 11 Engine noise level 27 Число тревог уровня масла
9 Left cylinder temperature 12 Ignition detonation delay angle 28 Engine hours on afterburn
10 Right cylinder temperature 13 Signal on the starter button 29 VTEC counter
11 Idle valve position 14 Neutral sensor 30 Engine hours in interrupted run time
12 Faults reading and reset 15 Emergency switch 31 Time of inlet air bypass valve
Honda additional parameters 16 Insufficient oil pressure 32 Number of motor starts
1 Generator 17 Excess oil pressure
33
2 Current of the idle speed valve 18 Water separator
+ faults reading and reset
State of the heated lambda probe
(air sensor pressure)
Current mix changes (short term correction
of the mix based on air sensor)
Coolant temperature, sensor 4
(air sensor heater)
1 rpm 6 Battery voltage 11 Gear
2 Fuel pressure 7 Fuel consumption 12 Faults
3 Engine oil pressure 8 Engine hours 13 Trim
4 Engine oil temperature 9 Engine load 14 Voltage
5 Engine coolant temperature 10 Fuel level in the tank
+ faults reading (without reset) ( )
